The gift cards domain model
This section describes the domain model that represents the gift card objects, where the following three assertions hold true:
- The domain model primarily serves as DTO objects for transferring information between the external commerce system and Sitecore.
- The domain model contains the minimum required information as contracts and will typically be extended, when integrated with a specific commerce system.
- The domain model is used when a Sitecore developer needs to synchronize product data with the external commerce system or product data is pushed into Sitecore from the external commerce system.
The following class diagram shows the domain model:
The domain model consists of abstract classes that make up the contracts with the external system. The contracts are defined as abstract classes instead of interfaces to allow the model to be easily extended later if needed. This follows the best practice guidelines defined in the Framework Design Guidelines.
A default implementation of the contracts is delivered as part of Connect. If an actual Connect provider with an external commerce system contains more functionality than provided by default, the implementation can be replaced. All instantiation of actual classes will be handled through dependency injection.
Class: GiftCard
The GiftCard class is responsible for representing a gift card entity in an external system.
| Name | Type | Description |
|---|---|---|
| ExternalId | String | Unique identifier for the product in the commerce system. This can be used to get a reference to the product using the commerce system's native API. |
| Name | String | The name, if any, of the gift card. |
| CustomerId | String | The identifier of the owner of the card. |
| ShopName | String | The shop the card is associated to if any. |
| CurrencyCode | String | The currency of the card value. |
| Balance | Decimal | The remaining value of the card. |
| OriginalAmount | Decimal | The initial value of the card. |
| Description | String | Reference to the manufacturers. |
Class: GiftCardPaymentInfo
The GiftCardPaymentInfo class is an implementation of the PaymentInfo class that allows a payment to be made with a gift card.
| Name | Type | Description |
|---|---|---|
| Amount | Decimal | The amount being charged against the gift card. |
| CardNumber | String | The ID of the gift card being used for payment. |
